Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 226 mm |
| Mount Hole Center - Center (O.1) | 132 mm |
| Mount Hole Diameter (C.1) | 10 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 104 mm |
| Unit Type | FORD |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | Explorer 4.0 V6 | 01.1991-12.1997 | |
| FORD | Mustang 4.0 | 01.2005-12.2010 | |
| FORD | Ranger 4.0 V6 | 01.1990-12.1997 | |
| MAZDA | B4000 4.0 | 01.1994-12.2009 | |
| MAZDA | Navajo 4.0 | 01.1991-12.1994 |
Reference Information
SDV38918 F77Z-11002-A STR8008 91-02-5852 STF2030 F2TZ-11002-A 880.513.102 F0TZ-11002-A F2TU-11000-AA STR8006 91-02-5852N UD20609S F07U-11000-AAVideo/Publications
880.513.102 91-02-5852 91-02-5852N F07U-11000-AA F0TZ-11002-A F2TU-11000-AA F2TZ-11002-A F77Z-11002-A SDV38918 STF2030 UD20609SAdd Your Number
