Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
HYUNDAI / KIA
Price:
NZ$ 328.27 including GST
NZ$ 285.45 excluding GST
or four payments of $82.07
with
Learn More
each
S9378S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Information
36100-03201Specifications
| Kilowatt | 0.90 kW |
| Length (L.1) | 182 mm |
| Mount Hole Center - Center (O.1) | 100 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 8 qty |
| OEM Product | No |
| Pinion at Rest (B) | 15 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 75 mm |
| Unit Type | HYUNDAI / KIA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | i10 1.2 | [G4LA] | 01.2008- |
| HYUNDAI | i20 1.2 | [G4LA] | 01.2008- |
| KIA | Picanto 1.0 | [G3LA] | 01.2011-12.2013 |
| KIA | Picanto 1.2 | [G4LA] | 01.2011-12.2013 |
| KIA | Rio 1.2 CVVT | [G4LA] | 01.2011- |
Reference Information
| 114760 | CARGO |
| 114821 | CARGO |
| 150.570.082.000 | PSH |
| 150.570.082.208 | PSH |
| 150.570.082.360 | PSH |
| 150.570.082.460 | PSH |
| 150.570.082.780 | PSH |
| 20405631OE | REAL |
| 220644 | ERA |
| 25-4285 | ELSTOCK |
| 30350N | WAI / TRANSPO |
| 36100-03100 | HYUNDAI / KIA |
| 36100-03150 | HYUNDAI / KIA |
| 36100-03200 | HYUNDAI / KIA |
| 36100-03201 | HYUNDAI / KIA |
| 36100-03400 | HYUNDAI / KIA |
| 36100-03402 | HYUNDAI / KIA |
| 6025136.1 | SANDO |
| ASM1525 | APEC |
| CS1517 | HC PARTS |
| CST25136GS | CASCO |
| DRS0558 | DELCO |
| F032114760 | CARGO |
| F032114821 | CARGO |
| J5210548 | HERTH+BUSS |
| JM000A15001 | HYUNDAI / KIA |
| JM000A18801 | HYUNDAI / KIA |
| LRS02612 | LUCAS |
| LRS2612 | LUCAS |
| MAV271360 | SIOM |
| NPANSM1525 | NAPA |
| S130.368 | PSH |
| S144.404 | PSH |
| S9378S | AS-PL |
| STR4197 | ELECTROLOG |
| STR54167 | WOODAUTO |
| STR8723 | ELECTROLOG |
| STV0902 | KRAUF |
| STX200428 | STARDAX |
| STX200921 | STARDAX |
| STX200921R | STARDAX |
| STX200922 | STARDAX |
| STX200922R | STARDAX |
| STX201289 | STARDAX |
| STX210281 | STARDAX |
| STX210281R | STARDAX |
| UD16971S | AS-PL |
| UD18569S | AS-PL |
