Specifications
| Kilowatt | 7.8 kW |
| Length (L.1) | 338 mm |
| Mount Hole Center - Center (O.1) | 89 mm |
| Mount Hole Center - Center (O.2) | 89 mm |
| Mount Hole Center - Center (O.3) | 126 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 48 mm |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | DENSO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CUMMINS | Engine | ||
| SAMSUNG | SE170 5.9 | [6BT] | 01.1992-12.1998 |
| SAMSUNG | SE210 5.9 | [6BT] | 01.1992-12.1999 |
| VOLVO | EC210 5.9 | [B5.9C] | 01.1996-12.2006 |
Reference Information
4934036 6040631.1 641.521.103.261 255022 641.521.103.262 255022C DENDSN2034 20432136BN 255022D 428080-5220 DSN2028 20432136OE DSN2034 428000-1330 S-80148 641.521.103.050 CST40631GS 3957598 UD18931S 336516 428080-1330 CST40631AS PRSE148 428000-5220 6040631 641.521.103.263 246-30227 UD100736S STRE148Video/Publications
20432136BN 20432136OE 246-30227 255022 255022C 255022D 3957598 428000-1330 428000-5220 428080-1330 428080-5220 4934036 6040631.0 6040631.1 641.521.103.050 641.521.103.261 641.521.103.262 641.521.103.263 CST40631AS CST40631GS DENDSN2034 DSN2028 PRSE148 S-80148 STRE148 UD18931SAdd Your Number
