Specifications
Kilowatt | 2.5 kW |
Length (L.1) | 301 mm |
Mount Hole Center - Center (O.1) | 142 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | 13 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 15 mm |
Rotation | CW |
Spigot Diameter (A) | 91 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Land Cruiser 4.2 D | [HDJ80] | 01.1990-12.2001 |
TOYOTA | Land Cruiser 4.2 TD | [HZJ7] | 01.1990-12.2001 |
Reference Information
UD17014S S-80287 228000-5993 428000-0521 246-25177 28100-17061 28100-17091Video/Publications
228000-5993 246-25177 28100-17061 28100-17091 428000-0521 S-80287 UD17014SAdd Your Number
