Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 235 mm |
| Mount Hole Center - Center (O.1) | 117 mm |
| Mount Hole Center - Center (O.2) | 78 mm |
| Mount Hole Center - Center (O.3) | 50 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| Mount Hole Diameter (C.3) | M10x1.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 2.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 50 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHRYSLER | 300 6.4 | 01.2012-12.2014 | |
| DODGE | Challenger 6.2 | 01.2015-12.2016 | |
| DODGE | Challenger 6.4 | 01.2011-12.2019 | |
| DODGE | Charger 6.2 | 01.2015-12.2015 | |
| DODGE | Charger 6.4 | 01.2012-12.2014 |
Reference Information
68066177AA UD17003S STR70436 19205N 428000-8390 830.962.133 S-80535Video/Publications
19205N 428000-8390 68066177AA 830.962.133 S-80535 STR70436 UD17003SAdd Your Number
