Specifications
| Kilowatt | 2.5 kW |
| Length (L.1) | 294 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 127 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 48 mm |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BLUEBIRD | Bus 5.9 | 01.1997-12.1998 | |
| BLUE BIRD | Bus 5.9 | 01.1994-12.1998 | |
| BLUE BIRD | Bus 5.9 | 01.1997-12.1998 | |
| CUMMINS | Engine | 01.1994-12.1994 | |
| FORD | B600 Series | [FD1060] | 01.1993-12.1999 |
| FORD | B700 Series | [FD1060] | 01.1993-12.1999 |
| FORD | B800 Series | [FD1060] | 01.1993-12.1999 |
| THOMAS BUILT BUSES | Bus 5.9 | 01.1992-12.1998 | |
| THOMAS BUILT BUSES | Bus 5.9 | 01.1996-12.1998 |
Reference Information
190-25106 228000-7301 228000-7300 228000-7960 STN9507 UD17007S DRS0353 2585095C91 DS1463 228000-3810 228000-3811 91-29-5401 F4HS-11001-HA S-8816 228000-4660 6040310 STN8507 18507N F042S00279 228000-4161 UD17006S 1760065 228000-4160 CST40310AS ANM12573X 20432013BN 246-25161Video/Publications
18507N 190-25106 20432013BN 228000-3810 228000-3811 228000-4160 228000-4161 228000-4660 228000-7300 228000-7301 228000-7960 246-25161 6040310.0 91-29-5401 CST40310AS DRS0353 DS1463 F042S00279 F4HS-11001-HA S-8816 STN8507 STN9507 UD17006S UD17007SAdd Your Number
