Associated Numbers
438000-1460, 438000-1461, 438000-1462
Ford FL3T11000AC, FL3T11000AE, FL3Z11002A, FL3Z11002B, SA1047
190-10303
UD20554S AS-PL
438000-1460 DENSOList
438000-1461 DENSO
438000-1462 DENSOList
S-80651 DIXIE
FL3T-11000-AC FORD
FL3T-11000-AE FORD
FL3Z-11002-A FORD
FL3Z-11002-B FORD
STM9571 KRAUF
34016N WAI / TRANSPO
91-29-5885 WILSON
Specifications
| Kilowatt | 1.2 kW |
| Length (L.1) | 215 mm |
| Mount Hole Center - Center (O.1) | 76 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 19 mm |
| Rotation | CW |
| Spigot Diameter (A) | 70 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | F150 2.7 | 01.2015-12.2019 |
Reference Information
34016N FL3Z-11002-B FL3Z-11002-A 91-29-5885 FL3T-11000-AE STR6753 FL3T-11000-AC STM9571 UD20554S 438000-1460 S-80651 438000-1462 438000-1461Video/Publications
34016N 438000-1460 438000-1461 438000-1462 91-29-5885 FL3T-11000-AC FL3T-11000-AE FL3Z-11002-A FL3Z-11002-B S-80651 STM9571 UD20554SAdd Your Number
