Associated Numbers
16-035 113239 Cargo 12214 EAI 1280008640 Denso 1280008641 1280008642 190573122 PSH 20513034 Prestolite 2280001610B 2280001611B 2280005990 show 2280005992 2280005993 2810017010 Toyota 2810017040B 2810017060 91295316 Wilson 91295316N ATS902 ATK F042000079 Bosch F042S00079 STR6072Bsa Electrolog STR6072sa STR6075sa STR6081 Unipoint dxs435 snj003 snj003GQ 70-8553 J N 410-52247 Substitutes: S6404 228000-1611 References: J& JANNCO 410-52247R 128000-8640 128000-8641 228000-1610 228000-629 228000-6290 228000-6291 Lester 18197 18424 PIC Picture ID 190-769 28100-17010 28100-17040 Yanmar 119773-77010 91-29-5316
113239 Cargo
1280008640 Denso
1280008641 Denso
1280008642 Denso
190573122 PSH
20513034 Prestolite
2280001610B Denso
2280001611B Denso
2280005990 Denso show
2280005992 Denso
2280005993 Denso
2810017010 Toyota
2810017040B Toyota
2810017060 Toyota
2810017090 Toyota
2810017091 Toyota
4280000520 Denso
4280000521 Denso
91295316 Wilson
91295316N Wilson
ATS902 ATK
F042000079 Bosch
F042S00079 Bosch
STR6081 Wood Auto
STR70101 Wood Auto
STR70230 Wood Auto
STR70295 Wood Auto
WOOSTR70101 Wood Auto
Specifications
| Kilowatt | 2.5 kW |
| Length (L.1) | 299 mm |
| Mount Hole Center - Center (O.1) | 140 mm |
| Mount Hole Diameter (C.1) | 13 mm |
| Mount Hole Diameter (C.2) | 13 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 12 qty |
| Pinion at Rest (B) | 16 mm |
| Rotation | CW |
| Spigot Diameter (A) | 91 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Land Cruiser 2.4 | [22R] | 11.1984-05.1993 |
| TOYOTA | Land Cruiser 2.4 | [22RE] | 12.1988-12.1996 |
| TOYOTA | Land Cruiser 2.4 | 01.1987- | |
| TOYOTA | Land Cruiser 2.4 80 4x4 | [22R] | 01.1990-05.1993 |
| TOYOTA | Land Cruiser 2.4 Diesel | [2L] | 11.1984-10.1985 |
| TOYOTA | Land Cruiser 2.4 TD | [2L-T] | 01.1990-05.1993 |
| TOYOTA | Land Cruiser 2.4 TD | [2L-T] | 07.1990-05.1996 |
| TOYOTA | Land Cruiser 2.4 TD | [2L-T] | 10.1985-05.1990 |
| TOYOTA | Land Cruiser 2.5 TD 4WD | 11.1984-12.1989 | |
| TOYOTA | Land Cruiser 2.5 TD 4x4 | 11.1984-12.1989 | |
| TOYOTA | Land Cruiser 2.6 D | [H] | 01.1975-07.1980 |
| TOYOTA | Land Cruiser 2.7 | [2TR-FE] | 11.2003- |
| TOYOTA | Land Cruiser 2.7 90 | 04.1995-07.2002 | |
| TOYOTA | Land Cruiser 2.8 TD 4x4 | [3L] | 01.1990-08.2001 |
| TOYOTA | Land Cruiser 3.0 D | [B] | 02.1974-10.1984 |
| TOYOTA | Land Cruiser 3.0 D-4D | [1KD-FTV] | 01.2003- |
| TOYOTA | Land Cruiser 3.0 D-4D | [1KD-FTV] | 08.2004- |
| TOYOTA | Land Cruiser 3.0 D-4D | [1KD-FTV] | 09.2002-02.2010 |
| TOYOTA | Land Cruiser 3.0 D-4D | [1KD-FTV] | 10.2000- |
| TOYOTA | Land Cruiser 3.0 TD | [1KZ-T] | 05.1993-05.1996 |
| TOYOTA | Land Cruiser 3.0 TD 4WD | [1KZ-TE] | 04.1996- |
| TOYOTA | Land Cruiser 3.0 TD 90 | [1KZ-TE] | 04.1995-07.2000 |
| TOYOTA | Land Cruiser 3.0 TD GX 90 Custom 4WD | [1KZ-T] | 01.1990-09.1991 |
| TOYOTA | Land Cruiser 3.4 | [3B] | 01.1981- |
| TOYOTA | Land Cruiser 3.4 | [3B] | 01.1982- |
| TOYOTA | Land Cruiser 3.4 | [3B] | 01.1983- |
| TOYOTA | Land Cruiser 3.4 | [3B] | 01.1984- |
| TOYOTA | Land Cruiser 3.4 | [3B] | 01.1985- |
| TOYOTA | Land Cruiser 3.4 | 09.2002-08.2004 | |
| TOYOTA | Land Cruiser 3.4 D | [3B] | 08.1980-10.1984 |
| TOYOTA | Land Cruiser 3.4 D | [3B] | 10.1981-08.1987 |
| TOYOTA | Land Cruiser 3.4 D | [3B] | 11.1984-12.1996 |
| TOYOTA | Land Cruiser 3.4 D 80 4x4 | 01.1990-12.1996 | |
| TOYOTA | Land Cruiser 3.4 TD | [13BT] | 10.1985-08.1986 |
| TOYOTA | Land Cruiser 3.5 80 FRT-Top 4WD | [1PZ] | 01.1990-08.1992 |
| TOYOTA | Land Cruiser 3.5 FRT-Top 4WD | [1PZ] | 01.1990-12.1994 |
| TOYOTA | Land Cruiser 3.6 D | [H] | 04.1979-07.1980 |
| TOYOTA | Land Cruiser 3.9 | [F] | 01.1973-01.1973 |
| TOYOTA | Land Cruiser 3.9 | [F] | 01.1974-01.1974 |
| TOYOTA | Land Cruiser 3.9 | [F] | |
| TOYOTA | Land Cruiser 3.9 | [FJ] | 01.1972- |
| TOYOTA | Land Cruiser 3.9 | ||
| TOYOTA | Land Cruiser 4.0 | [1GR-FE] | 01.2003- |
| TOYOTA | Land Cruiser 4.0 | [3F] | 11.1984-08.1987 |
| TOYOTA | Land Cruiser 4.0 | [3F-E] | 01.1988-01.1992 |
| TOYOTA | Land Cruiser 4.0 | [3F-E] | 01.1990-08.1992 |
| TOYOTA | Land Cruiser 4.0 | [3F-E] | 08.1987-12.1989 |
| TOYOTA | Land Cruiser 4.0 | 09.2002-08.2004 | |
| TOYOTA | Land Cruiser 4.0 D | [2H] | 01.1982-12.1985 |
| TOYOTA | Land Cruiser 4.0 D | [2H] | 01.1985-12.1987 |
| TOYOTA | Land Cruiser 4.0 D | [2H] | 08.1980-10.1984 |
| TOYOTA | Land Cruiser 4.0 D | [2H] | 10.1981-01.1988 |
| TOYOTA | Land Cruiser 4.0 D 4x4 | [2H] | 08.1987-12.1989 |
| TOYOTA | Land Cruiser 4.0 TD | [12HT] | 10.1985-12.1989 |
| TOYOTA | Land Cruiser 4.0 TD 4x4 | 01.1997-08.2001 | |
| TOYOTA | Land Cruiser 4.2 | [2F] | 01.1975-01.1977 |
| TOYOTA | Land Cruiser 4.2 | [2F] | 01.1975-04.1986 |
| TOYOTA | Land Cruiser 4.2 | [2F] | 01.1978-01.1978 |
| TOYOTA | Land Cruiser 4.2 | [2F] | 01.1979-01.1987 |
| TOYOTA | Land Cruiser 4.2 | [2F] | 10.1981-01.1988 |
| TOYOTA | Land Cruiser 4.2 | 01.1981- | |
| TOYOTA | Land Cruiser 4.2 | 01.1982- | |
| TOYOTA | Land Cruiser 4.2 | 01.1983- | |
| TOYOTA | Land Cruiser 4.2 | 01.1984- | |
| TOYOTA | Land Cruiser 4.2 | 01.1985- | |
| TOYOTA | Land Cruiser 4.2 | 01.1986- | |
| TOYOTA | Land Cruiser 4.2 | 01.1987- | |
| TOYOTA | Land Cruiser 4.2 D | [1H-Z] | 01.1990-12.1997 |
| TOYOTA | Land Cruiser 4.2 TD | [1HD-FT] | 03.1995-12.1997 |
| TOYOTA | Land Cruiser 4.2 TD | [1HD-T] | 01.1990-12.1997 |
| TOYOTA | Land Cruiser 4.2 TD | [1HD-T] | 10.1992-12.1997 |
| TOYOTA | Land Cruiser 4.2 TD | [1H-Z] | 01.1990- |
| TOYOTA | Land Cruiser 4.2 TD 100 | [1HD-FTE] | 01.1998- |
| TOYOTA | Land Cruiser 4.2 TD 90 4WD | 08.1999-08.2001 | |
| TOYOTA | Land Cruiser 4.2 TDi 24V 100 | [1HD-FTE] | 01.1998-07.2008 |
| TOYOTA | Land Cruiser 4.5 | [1FZ-FE] | 01.1993-01.1995 |
| TOYOTA | Land Cruiser 4.5 | [1FZ-FE] | 01.1996-01.1997 |
| TOYOTA | Land Cruiser 4.5 24V | [1FZ-FE] | |
| TOYOTA | Land Cruiser 4.7 | [2UZ-FE] | 01.1998-01.1998 |
| TOYOTA | Land Cruiser 4.7 | [2UZ-FE] | 01.1999-01.2001 |
| TOYOTA | Land Cruiser 4.7 | [2UZ-FE] | 01.2002-01.2002 |
| TOYOTA | Land Cruiser 4.7 | [2UZ-FE] | 01.2003- |
| TOYOTA | Land Cruiser 4.7 | [2UZ-FE] | 01.2004- |
| TOYOTA | Land Cruiser 4.7 | [2UZ-FE] | 01.2005- |
| TOYOTA | Land Cruiser 4.7 | [2UZ-FE] | 01.2007- |
| TOYOTA | Land Cruiser 4.7 | [2UZ-FE] | 02.2002- |
| TOYOTA | Land Cruiser 4.7 90 | 08.2002- | |
| TOYOTA | Land Cruiser 4.7 V8 32V | [2UZ-FE] | 01.1998- |
| TOYOTA | Land Cruiser 5.7 | [3UR-FE] | 01.2008- |
Reference Information
113239 91-29-5316 CST40208AS 28100-17010 254253 STN3239 18197N S-8568 UD17013S 20432802BN 128000-8641 128000-8640 MAV422080 CGB-23039 12214 STR70101 2810017090 228000-1610 228000-1611 6040208 28100-17040 28100-17060 S6404S STN9239 88213839 28100-17090 2810017061 18424N 246-25127 91-29-5316N 20513034 190.573.122 F042S00079 STR6072Video/Publications
113239 12214 128000-8640 128000-8641 18197N 18424N 190.573.122 20432802BN 20513034 228000-1610 228000-1611 246-25127 254253 28100-17010 28100-17040 6040208.0 88213839 91-29-5316 91-29-5316N CGB-23039 CST40208AS F042S00079 MAV422080 S-8568 STN3239 STN9239 STR70101 UD17013SAdd Your Number
