Specifications
Kilowatt | 0.8 kW |
Length (L.1) | 201 mm |
Mount Hole Center - Center (O.1) | 139 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 31 mm |
Rotation | CW |
Spigot Diameter (A) | 75 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ACURA | EL 1.7 | 01.2001-12.2005 | |
HONDA | Civic 1.7 | 01.2001-12.2005 |
Reference Information
DDVDH 91-29-5633 S-80012 EAA-141486 DRS3926 228000-9641 DDVD4 31200PLCT011M UD20505S DSDEU 17845R 17845N DRS3926N STR6237 DS5036N STN3704 31200P7AJ01 6040235 91-29-5633N 31200PLCT01 CST40235AS 20432532BN S6398S 31200PLRA01 31200PLRA02 31200PLRAO2 DS5036Video/Publications
17845N 17845R 228000-9641 91-29-5633 91-29-5633N S-80012 STN3704 UD20505S EAA-141486 20432532BN DRS3926 DS5036 DRS3926N CST40235AS DS5036N 6040235.0Add Your Number
