Specifications
Kilowatt | 1.2 kW |
Length (L.1) | 179 mm |
Mount Hole Center - Center (O.1) | 110 mm |
Mount Hole Diameter (C.1) | 9 mm |
Mount Hole Diameter (C.2) | 9 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 18 mm |
Rotation | CW |
Spigot Diameter (A) | 66 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
KUBOTA | Engine | [V1405] | 01.1992- |
KUBOTA | Engine | [V1505-B] | 01.1992- |
Reference Information
253969000RB 191-2229 228000-0950 CST40144AS 228000-0951 20432441BN 18400N UD810203(DENSO)S 25-3001 STR70488 690.509.092 6040144 LRS1526 LRS01526 20432441OE 1628563010 6040144.1 111622 228080-0951 STN1622 DSN2065 MAV421440 DENDSN2065 3756063012 253969000 37560-63012 3756063011 37560-63011 16285-63011 16285-63012 1759463012 3756063010 STR6192 CST40144GS MAV421440AVideo/Publications
111622 16285-63011 16285-63012 18400N 228000-0950 228000-0951 228080-0951 25-3001 690.509.092 DENDSN2065 LRS01526 LRS1526 STN1622 STR70488 UD810203(DENSO)SAdd Your Number
