Specifications
Kilowatt | 0.8 kW |
Length (L.1) | 205 mm |
Mount Hole Center - Center (O.1) | 110 mm |
Mount Hole Diameter (C.1) | 9 mm |
Mount Hole Diameter (C.2) | 9 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 8 qty |
Pinion at Rest (B) | 29 mm |
Rotation | ACW |
Spigot Diameter (A) | 65 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
SUZUKI | Carry 1.3 | [G13B] | 01.1999- |
SUZUKI | Super Carry 1.3 | [G13BB] | 01.1999-12.2004 |
Reference Information
31100-77A00 31339N 3110060B52 31339R UD17080S STN6133 STR6209 20432262BN CST40262AS LRS01731 25-3288 6040262 228000-6791 ANM12266X 114773 180.504.082 DRS0046 S6372S 254406 LRS1731 STR70102Video/Publications
114773 180.504.082 20432262BN 228000-6791 25-3288 254406 31100-77A00 3110060B52 31339N 31339R 6040262.0 CST40262AS DRS0046 LRS01731 LRS1731 STN6133 STR70102 UD17080SAdd Your Number
