Specifications
Kilowatt | 4.5 kW |
Length (L.1) | 297 mm |
Mount Hole Center - Center (O.1) | 146 mm |
Mount Hole Diameter (C.1) | M14x1.5 mm |
Mount Hole Diameter (C.2) | M14x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 16 mm |
Rotation | CW |
Spigot Diameter (A) | 105 mm |
Unit Type | DENSO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Dyna 150 3.4 D | [3B] | 09.1988-06.1995 |
TOYOTA | Dyna 200 3.4 D | [3B] | 10.1989-05.1995 |
TOYOTA | Dyna 3.0 D | [B] | 08.1977-10.1984 |
TOYOTA | Dyna 3.4 D | [13B] | 09.1984-08.1987 |
TOYOTA | Land Cruiser 3.0 D 4WD | [B] | 03.1969-10.1984 |
TOYOTA | Land Cruiser 3.4 D | [3B] | 11.1984-12.1996 |
TOYOTA | Land Cruiser 3.4 Diesel | [3B] | 10.1981-08.1987 |
TOYOTA | Land Cruiser 3.4 TD | [13BT] | 10.1985-08.1986 |
TOYOTA | Land Cruiser J40 3.4 | [B/3B] | 01.1977- |
TOYOTA | Land Cruiser J42 3.4 | [B/3B] | 01.1977- |
Reference Information
2810056151 2810056150 16967N CST40607AS 6040659 STR6208 MAV426070A 191.513.112 J5212019 J5212016 STN0761 254469 UD16848S 91-29-5056 2.81006E+11 2810057070 2810057071 28100-56071 2810056260 20432706BN 2810056100 2810056221 CST40659AS 2810056220 33918 20432956BN 2810056101 2810056222 6040607 MAV426590A MAV426210 280005540 2810056070 3309Video/Publications
0280005540 16967N 191.513.112 20432706BN 254469 28100-56071 2810056070 3309 33918 45-1071 91-29-5056 J5212016 J5212019 LRS01841 LRS1841 MAV426210 STN0761 UD16848SAdd Your Number
