Specifications
Kilowatt | 0.9 kW |
Length (L.1) | 189 mm |
Mount Hole Center - Center (O.1) | 100 mm |
Mount Hole Diameter (C.1) | 9 mm |
Mount Hole Diameter (C.2) | 9 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 16 mm |
Rotation | ACW |
Spigot Diameter (A) | 75 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
KAWASAKI | Engine | [FD731V] |
Reference Information
428000-4231 CST40548AS 428000-4230 190-10271 UD20474S 21163-2128 400.528.092 STN4230 19918N 6040548Video/Publications
190-10271 19918N 21163-2128 400.528.092 428000-4230 428000-4231 6040548.0 CST40548AS STN4230 UD20474SAdd Your Number
