Specifications
| Kilowatt | 1 kW |
| Length (L.1) | 189 mm |
| Mount Hole Center - Center (O.1) | 120 mm |
| Mount Hole Diameter (C.1) | 13.5 mm |
| Mount Hole Diameter (C.2) | 13.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 21 mm |
| Rotation | CW |
| Spigot Diameter (A) | 95 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| JOHN DEERE | 1445 1.0 | [3TNE78] | 01.2001-12.2003 |
| JOHN DEERE | 1445 1.3 | [3TNV82] | 01.2003-12.2015 |
| JOHN DEERE | 1545 1.0 | [3TNE78] | 01.2003-12.2004 |
| JOHN DEERE | 1545 1.3 | [3TNV82] | 01.2004-12.2015 |
Reference Information
S-80271 246-11104 114400 LRS01292 6040217 YM124520-77012 124520-77012 18427N 20432712BN AM880840 YM12452077011 YM12452077012 91-29-5591 228000-8090 CST40217AS LRS1292 UD16974S 980.539.132 71-29-18427 336463 12452077011 12452077012 25-2020 DRS0183 254416 JS1239Video/Publications
110485 114400 18427N 20432712BN 228000-8090 246-11104 25-2020 254416 6040217.0 71-29-18427 91-29-5591 980.539.132 CST40217AS DRS0183 JS1239 LRS01292 LRS1292 S-80271 UD16974SAdd Your Number
