Associated Numbers
Repco Auto Parts Starter Motor STR-314 STARTER MOTOR 1 UNIT Shine N16224 N16828 Toyota 28100-60070 WAI 2-1040 Wilson 91-29-5006 91-29-5017 91-29-5057 Denso 028000-2364 28100-60042 12v 1kw 028000-2800 21170-50100 028000-2801 028000-3820 28100-60062 028000-3821 28100-60060 028000-3822 28100-60061 028000-3824 028000-8220 028000-8221 028000-9020 28100-37011 0.8kw Hyster 3049481 Ingram 843001 843017 Lester 16224 16764 16828 Lucas LRS1013 LRS1057 LRS580 Mitsubishi MOT80685 AED 099-13-828 Ashdown 01-72301 01-76041 01-78220 RXS413 CW Electrics Australia ASND8220 Baxters S-8962 Bosch BXT128 JXS021 JXS028 Daiwa Machinery 28000-8220 028000-0430 28100-60010 028000-0431 028000-1370 28100-60040 028000-1371 28100-60041 028000-1372 028000-2360 028000-2361 028000-2362 28000-60041 028000-2363 DXS400Specifications
Kilowatt | 1 kW |
Length (L.1) | 178 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | 12 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 17 mm |
Rotation | CW |
Spigot Diameter (A) | 82.5 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Land Cruiser 4.0 | 01.1988-12.1988 | |
TOYOTA | Land Cruiser 4.0 | 01.1989-12.1989 | |
TOYOTA | Land Cruiser 4.0 | 01.1990-12.1990 | |
TOYOTA | Land Cruiser 4.0 | 01.1991-12.1991 | |
TOYOTA | Land Cruiser 4.0 | 01.1992-12.1992 | |
TOYOTA | Land Cruiser 4.2 | 01.1982-12.1982 | |
TOYOTA | Land Cruiser 4.2 | 01.1983-12.1983 | |
TOYOTA | Land Cruiser 4.2 | 01.1984-12.1984 | |
TOYOTA | Land Cruiser 4.2 | 01.1985-12.1985 | |
TOYOTA | Land Cruiser 4.2 | 01.1986-12.1986 | |
TOYOTA | Land Cruiser 4.2 | 01.1987-12.1987 |
Reference Information
LRS1762 131290084 26-0369 1336073C1 2810060014 16828N 455591 20432442BN 2810060010 MAV422440A 2810063020 16828R 2810063021 ESA359 2810060051 2810063040 S-8349 2810060090 UD16979S 6040244 LRS01762 CST40244AS 91-29-5057 28100-60080 CGB-23071 28100-63021 2810060042 131290099 2810060041 2810060060 2810060040 2810060062 131290079 2810060061 2810060080 STR3081 ESA153 MAV421280 STR70171 028000-8220 28100-63020 28100-63040 28100-60070Video/Publications
028000-8220 16828N 16828R 26-0369 28100-60070 455591 91-29-5057 CGB-23071 LRS01762 LRS1762 MAV421280 S-8349 STR70171 UD16979SAdd Your Number
