Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 225 mm |
Mount Hole Center - Center (O.1) | 113 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 7 mm |
Rotation | CW |
Spigot Diameter (A) | 81.5 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHRYSLER | Grand Voyager 3.3 i | [R00] | 01.1995-03.2001 |
CHRYSLER | Voyager 3.3 i | [R00] | 01.1995-03.2001 |
Reference Information
830.504.092 88213267 LRS1692 04686045AB 91-29-5492N CS1501 228000-7641 228000-7640 STR70255 STN4135 UD16976S 114135 LRS01692 S-8917 17784R 91-29-5492 17784N 25-3240Video/Publications
04686045AB 114135 17784N 17784R 228000-7640 228000-7641 25-3240 830.504.092 88213267 91-29-5492 91-29-5492N CS1501 LRS01692 LRS1692 S-8917 STN4135 STR70255 UD16976SAdd Your Number
