Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 189 mm |
| Mount Hole Center - Center (O.1) | 104 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 20 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | 4 Runner 2.7 | [3RZ-FE] | 01.1995-12.2000 |
| TOYOTA | Hi-Ace 2.0 | [1RZ] | 01.1993- |
| TOYOTA | Hi-Ace 2.4 | [2RZ-E] | 01.1993-12.1995 |
| TOYOTA | Hi-Ace 2.4 | [2RZ-E] | 01.1995-12.1998 |
| TOYOTA | Hi-Lux 2.4 | [RZ-FE] | 01.1998- |
Reference Information
17668N 2810075091 CST40408 2810075090 F004A94007 228000-2570 336528 25-2239 UD16975S 2280002573 DRS3848 2280002572 201101 2280002571 2810042040 2280003262 228000-3282 20432804OE 91-29-5273 000F004A94012 17668 2280002574 S-8454 88212892 6040408 190.540.092 281000C041 281000C040 F004A94012 STN1101 2280001690 LRS01378 J5212102 000F004A94007 MAV461060 28100-0C010 LRS1378Video/Publications
17668 17668N 190.540.092 201101 20432804OE 228000-2570 2280001690 2280002571 2280002572 2280002573 2280002574 2280003262 25-2239 281000C040 281000C041 2810042040 2810075090 2810075091 6040408 88212892 91-29-5273 CST40408 DRS3848 F004A94007 F004A94012 J5212102 LRS01378 LRS1378 MAV461060 S-8454 STN1101 UD16975SAdd Your Number
