Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MITSUBISHI
Price:
NZ$ 282.12 including GST
NZ$ 245.32 excluding GST
or four payments of $70.53
with
Learn More
each
S5461S
1
Information
M0T39671Specifications
| Kilowatt | 1.40 kW |
| Length (L.1) | 183.50 mm |
| Mount Hole Center - Center (O.1) | 101 mm |
| Mount Hole Diameter (C.1) | 10.50 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 7.50 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MAZDA | 6 2.5 | [PY..] | 01.2018- |
| MAZDA | CX-5 2.5 | [PV-VPTS] | 01.2017- |
| MAZDA | CX-5 2.5 | [PYZ..] | 01.2017- |
| MAZDA | CX-5 2.5 AWD | [PV-VPTS] | 01.2017- |
| MAZDA | CX-5 2.5 AWD | [PYZ..] | 01.2017- |
Reference Information
| 11040953 | EUROTEC |
| 11713N | WAI / TRANSPO |
| 25-5319 | ELSTOCK |
| 91-27-3545 | WILSON |
| 9919 | CEVAM |
| AEY4156 | AUTOELECTRO |
| DRS1425 | DELCO |
| LRS04156 | LUCAS |
| LRS4156 | LUCAS |
| M000T39671 | MITSUBISHI |
| M0T39671 | MITSUBISHI |
| PY01-18-400 | MAZDA |
| PY0I18400 | MAZDA |
| S-80589 | DIXIE |
| STM7281 | KRAUF |
| STM9281 | KRAUF |
| STR5422 | ELECTROLOG |
| UD18548S | AS-PL |
Video/Publications
