Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 183.5 mm |
| Mount Hole Center - Center (O.1) | 101 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 7.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MAZDA | 6 2.5 | [PY..] | 01.2018- |
| MAZDA | CX-5 2.5 | [PV-VPTS] | 01.2017- |
| MAZDA | CX-5 2.5 | [PYZ..] | 01.2017- |
| MAZDA | CX-5 2.5 AWD | [PV-VPTS] | 01.2017- |
| MAZDA | CX-5 2.5 AWD | [PYZ..] | 01.2017- |
Reference Information
AEY4156 UD18548S STR5422 STM9281 25-5319 11040953 9919 STM7281 DRS1425 LRS04156 M000T39671 91-27-3545 LRS4156 11713N M0T39671 PY01-18-400 PY0I18400 S-80589Video/Publications
11040953 11713N 25-5319 91-27-3545 9919 AEY4156 DRS1425 LRS04156 LRS4156 M000T39671 M0T39671 PY01-18-400 PY0I18400 S-80589 STM7281 STM9281 UD18548SAdd Your Number
