Specifications
Kilowatt | 5.5 kW |
Length (L.1) | 404 mm |
Mount Hole Center - Center (O.1) | 126 mm |
Mount Hole Center - Center (O.2) | 126 mm |
Mount Hole Center - Center (O.3) | 126 mm |
Mount Hole Diameter (C.1) | 14 mm |
Mount Hole Diameter (C.2) | 14 mm |
Mount Hole Diameter (C.3) | 14 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VOLVO | VNL 16.1 | [D16] | 01.2006-12.2006 |
VOLVO | VT 16.1 | [D16] | 01.2005-12.2006 |
Reference Information
22809740 20712113 S-80243 M009T70879 UD18605S VV0879 M9T70879 91-27-3398Video/Publications
20712113 22809740 91-27-3398 M009T70879 M9T70879 S-80243 UD18605S VV0879Add Your Number
