Specifications
Kilowatt | 2.2 kW |
Length (L.1) | 245 mm |
Mount Hole Center - Center (O.1) | 104 mm |
Mount Hole Center - Center (O.2) | 108 mm |
Mount Hole Center - Center (O.3) | 71 mm |
Mount Hole Diameter (C.1) | 7.5 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 17 qty |
Pinion at Rest (B) | 21 mm |
Rotation | CW |
Spigot Diameter (A) | 68 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
BUICK | Encore 1.4 | 01.2016- | |
CHEVROLET | Cruze 1.4 | 01.2016- | |
CHEVROLET | Cruze 1.5 | 01.2016- | |
CHEVROLET | Malibu 1.4 | 01.2016- | |
CHEVROLET | Malibu 1.5 | 01.2016- |
Reference Information
STM1940 12648892 M8T72172 12668168 UD17280S 12664302 12680617 M008T72172Video/Publications
12648892 12664302 12668168 12680617 M008T72172 M8T72172 STM1940 UD17280SAdd Your Number
