Specifications
Kilowatt | 3.2 kW |
Length (L.1) | 259 mm |
Mount Hole Center - Center (O.1) | 115 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 22 mm |
Rotation | CW |
Spigot Diameter (A) | 82.5 mm |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MITSUBISHI | Engine | [S4S] | |
MITSUBISHI | Engine | [S4S-T] | |
MITSUBISHI | FD-20 | ||
MITSUBISHI | FD-20B-D | ||
MITSUBISHI | FD-20B-DS | ||
MITSUBISHI | FD-20D | ||
MITSUBISHI | FD-25 | ||
MITSUBISHI | FD-25B-D | ||
MITSUBISHI | FD-25B-DS | ||
MITSUBISHI | FD-25D | ||
MITSUBISHI | FD-25T | ||
MITSUBISHI | FD-35A | ||
MITSUBISHI | FD-35AB-D | ||
MITSUBISHI | FD-35AT |
Reference Information
BOM UNIT 20437676OE M002TS5071 M2T66271 STM5927 151.526.102 STR5477 M2TS5071 32A6600201 103-5270 32A6601200 130-20101 6035676.1 CST35676GS M002T66271 UD17040SVideo/Publications
130-20101 151.526.102 20437676OE 32A6600201 32A6601200 6035676.1 CST35676GS M002T66271 M002TS5071 M2T66271 M2TS5071 STM5927 UD17040S UNIT BOM 103-5270Add Your Number
