Specifications
Kilowatt | 1.2 kW |
Length (L.1) | 183 mm |
Mount Hole Center - Center (O.1) | 76 mm |
Mount Hole Center - Center (O.2) | 108 mm |
Mount Hole Center - Center (O.3) | 73 mm |
Mount Hole Diameter (C.1) | 9 mm |
Mount Hole Diameter (C.2) | 9 mm |
Mount Hole Diameter (C.3) | M8x1.25 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 10 mm |
Rotation | CW |
Spigot Diameter (A) | 64 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DODGE | Dart 1.4 | 01.2013-12.2013 | |
DODGE | Dart 1.4 | 01.2014-12.2014 | |
DODGE | Dart 1.4 | 01.2015-12.2015 | |
DODGE | Dart 1.4 | 01.2016-12.2016 | |
FIAT | 500 1.4 | 01.2014-12.2014 | |
FIAT | 500 1.4 | 01.2015-12.2015 | |
FIAT | 500 1.4 | 01.2016-12.2016 | |
FIAT | 500 1.4 | 01.2017-12.2017 | |
FIAT | 500 1.4 | 01.2018-12.2018 |
Reference Information
M0T33872 10874N UD20441S S-80560 M0T33872ZC 91-27-3553 M000T33872Video/Publications
10874N 91-27-3553 M000T33872 M0T33872 M0T33872ZC S-80560 UD20441SAdd Your Number
