Specifications
Kilowatt | 8.3 kW |
Length (L.1) | 417 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
Mount Hole Diameter (C.3) | 13.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | LUCAS/MARELLI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MERCEDES BENZ TRUCKS & BUSES | Various Models |
Reference Information
LES0321 UD16952SVideo/Publications
LES0321 UD16952SAdd Your Number
