Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MAGNETI MARELLI
Price:
NZ$ 235.51 including GST
NZ$ 204.79 excluding GST
or four payments of $58.88
with
Learn More
each
S0103
S4071S
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
Information
63223103Specifications
| Kilowatt | 0.8 kW |
| Length (L.1) | 222 mm |
| Mount Hole Center - Center (O.1) | 84 mm |
| Mount Hole Center - Center (O.2) | 70 mm |
| Mount Hole Center - Center (O.3) | 110 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 42 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | ACW |
| Spigot Diameter (A) | 67 mm |
| Unit Type | MAGNETI MARELLI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ROVER | 111 1.1 Metro | [11K2A] | 03.1990-12.1998 |
| ROVER | 111 1.1 Metro | [11K2D] | 03.1990-12.1998 |
| ROVER | 111 1.1 Metro | [11K2D] | 04.1994-10.1997 |
| ROVER | 114 1.4 | [14K2D] | 03.1990-12.1998 |
| ROVER | 114 1.4 | [14K4F] | 03.1997-10.1998 |
| ROVER | 114 1.4 | [TUD3] | 10.1992-12.1994 |
| ROVER | 114 1.4 16V Metro | [14K4C] | 03.1990-12.1998 |
| ROVER | 114 1.4 16V Metro | [14K4D] | 03.1990-12.1998 |
| ROVER | 114 1.4 GSi | [14K4F] | 10.1994-10.1995 |
| ROVER | 114 1.4 GTi 16V | [14K4F] | 08.1991-12.1998 |
| ROVER | 114 1.4 GTi 16V Metro | [14K4C] | 03.1990-08.1991 |
| ROVER | 114 1.4 GTi 16V Metro | [14K4D] | 03.1990-08.1991 |
| ROVER | 114 1.4 Metro | [14K2A] | 03.1990-12.1998 |
| ROVER | 114 1.4 Metro | [14K2A] | 04.1994-10.1997 |
| ROVER | 114 1.4 Metro | [14K2D] | 04.1994-10.1997 |
| ROVER | 211 1.1 | [11K2D] | 01.1998-03.2000 |
| ROVER | 214 1.4 | [14K2A] | 09.1993-10.1995 |
| ROVER | 214 1.4 | [14K2D] | 09.1993-10.1995 |
| ROVER | 214 1.4 | [14K4C] | 01.1990-10.1995 |
| ROVER | 214 1.4 | [14K4C] | 04.1990-09.1992 |
| ROVER | 214 1.4 | [14K4C] | 10.1989-10.1995 |
| ROVER | 214 1.4 | [14K4D] | 10.1989-10.1995 |
| ROVER | 214 1.4 | [14K4F] | 12.1992-10.1995 |
| ROVER | 214 1.4 i | [14K2F] | 11.1995-03.2000 |
| ROVER | 214 1.4 i | [14K4C] | 01.1992-11.1999 |
| ROVER | 214 1.4 i | [14K4D] | 01.1992-11.1999 |
| ROVER | 214 1.4 i | [14K4F] | 01.1993-11.1999 |
| ROVER | 214 1.4 Si | [14K4F] | 11.1995-03.2000 |
| ROVER | 216 1.6 i | [16K4F] | 01.1996-11.1999 |
| ROVER | 216 1.6 Si | [16K4F] | 11.1995-03.2000 |
| ROVER | 25 1.1 16V | [11K4F] | 01.2004-05.2005 |
| ROVER | 25 1.4 16V | [14K4F] | 10.1999-05.2005 |
| ROVER | 25 1.4 16V | [14K4M] | 10.1999-05.2005 |
| ROVER | 25 1.6 16V | [16K4F] | 10.1999-05.2005 |
| ROVER | 400 1.4 | [14K2F] | 03.1996-12.1997 |
| ROVER | 414 1.4 | [14K4C] | 04.1990-04.1995 |
| ROVER | 414 1.4 | [14K4D] | 04.1990-04.1995 |
| ROVER | 414 1.4 | [14K4F] | 01.1993-04.1995 |
| ROVER | 414 1.4 Si | [14K4F] | 05.1995-03.2000 |
| ROVER | 416 1.6 16V | [16K4F] | 03.1996-11.1999 |
| ROVER | 416 1.6 Si | [16K4F] | 05.1995-03.2000 |
| ROVER | 416 1.6 Si | [D16Y2] | 05.1995-03.2000 |
| ROVER | 416 1.6 Si | [D16Y2] | 06.1995-03.2000 |
| ROVER | 45 1.4 | [14K4F] | 02.2000- |
| ROVER | 45 1.6 | [16K4F] | 02.2000- |
| ROVER | Commerce 1.4 | 01.2003-12.2005 | |
| ROVER | Streetwise 1.4 | [14K4F] | 08.2003- |
Reference Information
6030142.0 STM582 LRS708 NAD100340 NAD101070 ADU1595 STB0610 GXE4607 NAD100740 63223103 63223104 CST30142AS 10610 NAD101080 63323104A NAD10034 NAD10033 AUU1595 TJG911023B MAV121950 GNU4900 NAD101080E CS610 NAD100750 GXE4597 458168 NAD10024 63323103A 450.008.093 GNU4813 GNU4814 STR90052 STX200098R 94323104 25-2131 94323103 UD20626S GNU4608 NAD000200 3670 113346 88212672 LRS00708 30709R 20404241BN GNU4607 905720100079 NAD101260 GXE4735 STX200098 GXE4736 220173 GNU4563 MSM641 NAD100330 STR52008 CGB-23205 MAV2440Video/Publications
