Specifications
Kilowatt | 2.2 kW |
Length (L.1) | 209 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 13 qty |
Pinion at Rest (B) | 19 mm |
Rotation | CW |
Spigot Diameter (A) | 79 mm |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | H-1 Cargo 2.5 CRDi | [D4CB] | 01.2009- |
HYUNDAI | H-1 Travel 2.5 CRDi | [D4CB] | 07.2010- |
HYUNDAI | H-1 Travel 2.5 CRDi | [D4CB] | 08.2011- |
HYUNDAI | H350 2.5 CRDi | [D4CB] | 04.2015- |
Reference Information
LRS4227 36100-4A900 36100-4A910 256250V 1207077 150.900.132.360 MAV341250 STA1728 220862 CST32162GS LRS04227 S0001207077 25-5389 MAV341620 6032162.1 UD20965S S3224S 20493261OE BN361004A900Video/Publications
1207077 150.900.132.360 20493261OE 220862 25-5389 256250V 36100-4A900 6032162.1 BN361004A900 CST32162GS LRS04227 LRS4227 MAV341250 MAV341620 S0001207077 STA1728 UD20965SAdd Your Number
