Specifications
Kilowatt | 2.2 kW |
Length (L.1) | 217 mm |
Mount Hole Center - Center (O.1) | 157 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | 13 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 37 mm |
Rotation | CW |
Spigot Diameter (A) | 85 mm |
Unit Type | HITACHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHEVROLET | Various Models | 01.2001-12.2010 | |
HUMMER | Various Models | 01.2006-12.2006 |
Reference Information
8980023950 S14-100DR 8972095484 S14-100D S14-100E 91-25-1158N 12670255 2902769410 UD20864S 91-25-1158 8973828350 97779551 830.540.092 S14-103A 17801N STH7801 S14-101A S14-103C S14-101B S14-101C S14-101D S14-103 S14-101AR S14-100 S14-101 2902769300 8972095483 STR72219 STR3085 8973291631Video/Publications
17801N 2902769300 2902769410 830.540.092 8972095483 8972095484 8973291631 8973828350 8980023950 91-25-1158 91-25-1158N S14-100 S14-100D S14-100DR S14-100E S14-101 S14-101A S14-101AR S14-101B S14-101C S14-101D S14-103 S14-103A STH7801 STR72219 UD20864SAdd Your Number
