Specifications
Kilowatt | 1.2 kW |
Length (L.1) | 217 mm |
Mount Hole Center - Center (O.1) | 19 mm |
Mount Hole Center - Center (O.2) | 106 mm |
Mount Hole Center - Center (O.3) | 110 mm |
Mount Hole Diameter (C.1) | M12x1.75 mm |
Mount Hole Diameter (C.2) | 9 mm |
Mount Hole Diameter (C.3) | M12x1.75 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 20 qty |
Pinion at Rest (B) | 19 mm |
Rotation | CW |
Spigot Diameter (A) | 80 mm |
Unit Type | HITACHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TAKEUCHI | TB125 | [3TNE82A] | 01.2009-12.2014 |
TAKEUCHI | TB135 | [3TNE88-TB] | 01.2009-12.2014 |
TAKEUCHI | TB145 | [3TNE88-TB] | 01.2009-12.2014 |
TAKEUCHI | TB228 | [3TNV82-QTB1] | 01.2009-12.2014 |
TAKEUCHI | TB230 | [3TNE88F] | 01.2009-12.2014 |
YANMAR | Engine | [3TNV82-QTB1] | |
YANMAR | Engine | [3TNV88F] | |
YANMAR | Engine | [3TNV88-QTB] | |
YANMAR | Engine | [4TNV88-QTB] | |
YANMAR | Engine | [FN12] |
Reference Information
CST20267AS S114438D 104-10328 6020267 980.534.203 240-14119 S114438C S114-438 S114438B 10510077010 10510077011 S114438 STR72119 UD17060S STH0438 STRE216 254418Video/Publications
104-10328 10510077010 10510077011 240-14119 254418 6020267.0 980.534.203 CST20267AS S114-438 S114438 S114438B S114438C S114438D STH0438 STR72119 STRE216 UD17060SAdd Your Number
