Specifications
Kilowatt | 9 kW |
Length (L.1) | 573 mm |
Mount Hole Center - Center (O.1) | 126 mm |
Mount Hole Center - Center (O.2) | 126 mm |
Mount Hole Center - Center (O.3) | 126 mm |
Mount Hole Diameter (C.1) | 16.5 mm |
Mount Hole Diameter (C.2) | 16.5 mm |
Mount Hole Diameter (C.3) | 16.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 97 mm |
Rotation | CW |
Spigot Diameter (A) | 101 mm |
Unit Type | DELCO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CATERPILLAR | 583H | [D342] | 01.1969-12.1974 |
CATERPILLAR | 583K | [D342] | 01.1974-12.1989 |
CATERPILLAR | 594 | [D353] | 01.1974-12.1974 |
CATERPILLAR | 594H | [D353] | 01.1974-12.1985 |
CATERPILLAR | D7E | [3306] | 01.1962-12.1970 |
CATERPILLAR | D8H | [D342] | 01.1958-12.1974 |
CATERPILLAR | D8K | [D342] | 01.1974-12.1982 |
CATERPILLAR | D9G | 01.1969-12.1974 | |
CATERPILLAR | D9H | [D353] | 01.1974-12.1982 |
INGERSOLL RAND | Various Models |
Reference Information
1990240 OR5214 1P9162 8S9542 20409816BN 20409816OE 3S4458 UD21051S 140-50762 1109849 1990247 50MT 3T8950 374458 1109632 CST60618AS 0R5214 3872N BS9542 1109273 1109792 91-01-4062 5L4431 8S3196 TS-1774 201-50217 10478862 1109757 3T2781 3T3430 8S9524 7N8604 10R1913 1P9182 STD8374 91-01-4062N 254223 1109949 6060618.1 254223D 641.043.123.515 6060618 1109497 STR80040 3604645RX 1109779 1990232 1993781 CST60618GSVideo/Publications
0374458 0R5214 10478862 10R1913 1109273 1109497 1109632 1109757 1109779 1109792 1109849 1109949 140-50762 1990232 1990240 1990247 1993781 1P9162 1P9182 201-50217 254223 254223D 3604645RX 3872N 3S4458 3T2781 3T3430 3T8950 50MT 641.043.123.515 7N8604 8S3196 8S9524 8S9542 91-01-4062 91-01-4062N STD8374 STR80040 TS-1774 UD21051SAdd Your Number
