Specifications
Kilowatt | 1.2 kW |
Length (L.1) | 211 mm |
Mount Hole Center - Center (O.1) | 70 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 22 mm |
Rotation | CW |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHEVROLET | Astro 4.3 V6 | 01.2004-12.2005 | |
CHEVROLET | Blazer 4.3 V6 | 01.2004-12.2005 | |
CHEVROLET | Express 4.3 V6 | 01.2004-12.2007 | |
GMC | Jimmy 4.3 V6 | 01.2004-12.2005 | |
GMC | Safari 4.3 V6 | 01.2004-12.2005 | |
GMC | Savana 4.3 V6 | 01.2004-12.2007 | |
GMC | Sonoma 4.3 V6 | 01.2004-12.2004 |
Reference Information
201-12103 6495 91-01-4642 6495N UD20586S S-1490 8000287 6495R 9000960 STD1624 91-01-4642NVideo/Publications
201-12103 6495 6495N 6495R 8000287 9000960 91-01-4642 91-01-4642N S-1490 STD1624 UD20586SAdd Your Number
