Specifications
Kilowatt | 1.7 kW |
Length (L.1) | 220 mm |
Mount Hole Center - Center (O.1) | 102 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 16 mm |
Rotation | CW |
Spigot Diameter (A) | 77 mm |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | ix35 1.7 CRDi | [D4FD] | 11.2010- |
KIA | Sportage 1.7 CRDi | [D4FD] | 12.2010- |
Reference Information
11040871 LRS2654 9961 STRF860D J5210539 CGB-54326 20493541OE S1096S LRS02654 CGB-20621 12178 8000396 8000496 36100-2A800 STRF860 6032145.1 STM1355 WRM32145OE STR80184 UD18567S 361002A830 115446 AEY2654 255043D STR2714 220743 PRSF860 150.577.112 PRSE445 36100-2A830 MAV341450 STD0496 25-4326 986027070 36100-2A810 336060 000986027070 CST32145GS STRE445Video/Publications
0986027070 11040871 115446 12178 150.577.112 20493541OE 25-4326 255043D 36100-2A800 36100-2A810 6032145.1 8000396 8000496 9961 AEY2654 CGB-20621 CGB-54326 CST32145GS J5210539 LRS02654 LRS2654 MAV341450 PRSE445 PRSF860 STD0496 STM1355 STR80184 STRE445 STRF860 STRF860D UD18567S WRM32145OE S1096S 220743Add Your Number
