Specifications
Kilowatt | 1.5 kW |
Length (L.1) | 214 mm |
Mount Hole Center - Center (O.1) | 119 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 13 qty |
Pinion at Rest (B) | 42 mm |
Rotation | ACW |
Spigot Diameter (A) | 79 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
AUDI | S3 2.0 Quattro | [CJXD] | 08.2016- |
AUDI | S3 2.0 Quattro | [CJXG] | 06.2016- |
AUDI | S3 2.0 Quattro | [DJHA] | 06.2016- |
AUDI | S3 2.0 Quattro | [DJHB] | 08.2016- |
AUDI | S3 2.0 Quattro Sportback | [CJXD] | 07.2016- |
AUDI | S3 2.0 Quattro Sportback | [CJXG] | 06.2016- |
AUDI | S3 2.0 Quattro Sportback | [DJHA] | 06.2016- |
AUDI | S3 2.0 Quattro Sportback | [DJHB] | 07.2016- |
SKODA | Superb 2.0 TSi | [CZPB] | 07.2019- |
SKODA | Superb 2.0 TSi | [DKZA] | 07.2019- |
SKODA | Superb 2.0 TSi | [DNNA] | 07.2019- |
VW | Arteon 2.0 TSi | [CZPB] | 05.2017- |
VW | Arteon 2.0 TSi | [DKZA] | 05.2017- |
VW | Golf VII 2.0 GTI TCR | [CJXH] | 11.2018- |
VW | Golf VII 2.0 GTI TCR | [DNUC] | 11.2018- |
VW | Golf VII 2.0 R 4-Motion | [CJXC] | 03.2015- |
VW | Golf VII 2.0 R 4-Motion | [CJXC] | 11.2013- |
VW | Golf VII 2.0 R 4-Motion | [CJXD] | 12.2016- |
VW | Golf VII 2.0 R 4-Motion | [CJXG] | 12.2016- |
VW | Golf VII 2.0 R 4-Motion | [DJHA] | 12.2016- |
VW | Golf VII 2.0 R 4-Motion | [DJHB] | 12.2016- |
VW | Golf VII 2.0 R 4-Motion | [DNUC] | 12.2016- |
VW | Golf VII 2.0 R 4-Motion | [DNUE] | 03.2015- |
VW | Golf VII 2.0 R 4-Motion | [DNUE] | 11.2013- |
Reference Information
0001177014 0001177015 6010568.1 CST10568GS AEY3856 MAV125680 02E911024N STB2468 02E911022HX 20401865OE UD17326S 1177015 1177014 02E911024MX 02E911024NXVideo/Publications
0001177014 0001177015 02E911024N 02E911024NX AEY3856 UD17326S STB2468Add Your Number
