Specifications
Kilowatt | 3.6 kW |
Length (L.1) | 385 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CLAAS | Dominator 100 | [OM360] | 01.1973-12.1974 |
CLAAS | Dominator 105 | [OM360.930] | 01.1974-12.1977 |
CLAAS | Dominator 106 | [OM360] | 01.1979-12.1985 |
MERCEDES BENZ TRUCKS & BUSES | 1113 5.7 | [OM352] | 01.1968-12.1983 |
MERCEDES BENZ TRUCKS & BUSES | 1113 5.7 | [OM353] | 01.1972-12.1973 |
MERCEDES BENZ TRUCKS & BUSES | 1313 5.7 | [OM352] | 01.1967-12.1973 |
MERCEDES BENZ TRUCKS & BUSES | 1313 5.7 | [OM353] | 01.1971-12.1973 |
MERCEDES BENZ TRUCKS & BUSES | 1513 5.7 | [OM352] | 01.1967-12.1973 |
MERCEDES BENZ TRUCKS & BUSES | 1513 5.7 | [OM353] | 01.1972-12.1973 |
MERCEDES BENZ TRUCKS & BUSES | 813 5.7 | [OM353] | 01.1973- |
MERCEDES BENZ TRUCKS & BUSES | 911 5.7 | [OM352] | 01.1968-12.1973 |
MERCEDES BENZ TRUCKS & BUSES | 911 5.7 | [OM353] | 01.1972-12.1973 |
MERCEDES BENZ TRUCKS & BUSES | 913 5.7 | [OM353] | 01.1969-12.1973 |
NEW HOLLAND | 1550S 8.7 | [OM360.970] | 01.1971-12.1979 |
Reference Information
2921436 C1R12X4H7622 TS-6005 550.204.113.311 1413003 STR50691 6.0572E+11 CGB-22402 625031112 BOM UNIT 0001401036 WOOSTR50691 1401036 105003 MAHMS584 CGB-11402 UD16934S 3119928 3119929 LRS01015 120-5120 0001413003 25-0125 STRJ597 1401037 19024001 IS9127 103932 STR79567 104286 1401044 1401045 0001401045 0001401044 STB1690 110409 72736212 C3R12X4H7622 550.204.113.016 AZK5487 0001418002 255632 550.204.113 1401005 0001401037 21518001 150442401 A0021518001 REM19024001 STR10117 1287138 81262016019 11.139.140 MS584 S510326 550.204.113.010 88213718 1418002 S0866S 1170054 0001401005 A75880 10438383 LRS1015Video/Publications
0001401044 0001413003 0001418002 001170054 0021518001 110409 25-0125 255632 2921436 550.204.113 81262016019 88213718 A0021518001 CGB-11402 LRS01015 LRS1015 STR50691 STRJ597 TS-6005 UD16934S UNIT BOM 120-5120 S0866SAdd Your Number
