Specifications
Kilowatt | 4 kW |
Length (L.1) | 301 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 128 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 30 mm |
Rotation | CW |
Spigot Diameter (A) | 88 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CASE | 621D 4.5 | [F4GE0684F] | 01.2002- |
CASE | 621D 4.5 D | [F4GE0684F] | 01.2002- |
CASE | CX220B | [F4GE0684B] | 01.2010- |
IVECO | Engine | [F4HE0685A] | |
NEW HOLLAND | E175B | [F4GE9484D] | 01.2007- |
Reference Information
72735867 88213991 220751 45-4203 CS1536 6010680.1 0001263019 EAA-121253 8095 1263019 MAHMS239 254204 63522630200 120-20195 114196 STRL260 ANM12247X S0865S S5015L 1231026 STR50211 19084220 LRS2531 1231027 DS1137 0001263020 S24BH0049A2 MAV126770 84377568 CST10680GS TS-6217 MAV126800 19796N AZF4295 UD16918S 0001231027 63522310260 0001231026 CGB-31026 000986025530 254204B 504385577 861084 EAA-121390 501.505.103.011 MSN2118 5801577136 501.505.103.012 501.505.103.212 501.505.103.215 MS239 20401086BN LRS02531 11.132.094 2852478 20401086OE STR10197 0001251006 0001251005 504036695 STR1565 1263020 501.505.103.280 CST10680AS STR1564 986025530 MSN2047 STB4196 STB8196 500389863 IS1341 6010680 DRS0027 BOS0001251006 S24BH0049 1251006 260-23217 1251005 CGB-21027 2852405 STM1268Video/Publications
0001231026 0001231027 0001251005 0001251006 0001263019 0001263020 063522310260 063522630200 0986025530 11.132.094 114196 120-20195 19084220 19796N 20401086BN 20401086OE 254204 254204B 260-23217 2852405 2852478 45-4203 500389863 501.505.103 504036695 504385577 5801577136 6010680.0 6010680.1 72735867 8095 88213991 AZF4295 BOS0001251006 CGB-21027 CGB-31026 CS1536 CST10680AS CST10680GS DRS0027 DS1137 IS1341 LRS02531 LRS2531 MAHMS239 MAV126770 MAV126800 MSN2047 MSN2118 S5015L STB4196 STB8196 STM1268 STRL260 TS-6217 UD16918S 220751Add Your Number
