Specifications
Kilowatt | 0.9 kW |
Length (L.1) | 194 mm |
Mount Hole Center - Center (O.1) | 88 mm |
Mount Hole Diameter (C.1) | M8x1.25 mm |
Mount Hole Diameter (C.2) | M8x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 8 mm |
Rotation | ACW |
Spigot Diameter (A) | 62 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
PIAGGIO | Various Models |
Reference Information
6010493.1 BOM STR1466 UNIT 254978B CST10493GS GU057030730 120-6317 STB6407 UD20331S 20401394OE BOS0001106402 1106407 0001106407 254978 1106402 410.503.092 0001106402 MAV6300 STRF048Video/Publications
0001106402 0001106407 20401394OE 254978 254978B 410.503.092 6010493.1 BOS0001106402 CST10493GS GU057030730 MAV6300 STB6407 STRF048 UD20331S UNIT BOM 120-6317Add Your Number
