Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 743.14 including GST
NZ$ 646.21 excluding GST
or four payments of $185.79
with
Learn More
each
S0855S
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
Information
0001401012Specifications
| Kilowatt | 3.6 kW |
| Length (L.1) | 385 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 127 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 47.5 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BOMAG | BW 4A 2.8 | [KHD-F3L912] | 01.1973-09.1984 |
| BOMAG | BW 6A 2.8 | [KHD-F3L912] | 01.1973- |
| VOLVO | B 705 4.7 | [D47B] | 01.1962-04.1964 |
| VOLVO | F 84 5.0 | [D50B] | 01.1972-12.1974 |
| VOLVO | F 84T 5.0 | [TD50B] | 01.1972-10.1978 |
| VOLVO | F 85 5.0 | [D50B] | 01.1972-12.1974 |
| VOLVO | F 85T 5.0 | [TD50B] | 01.1972-10.1978 |
| VOLVO | F 86 6.7 | [D70B] | 06.1970-12.1974 |
| VOLVO | F 86T 6.7 | [TD70B] | 08.1970-09.1974 |
| VOLVO | FB 84 5.0 | [D50B] | 01.1972-12.1974 |
| VOLVO | FB 84T 5.0 | [TD50B] | 01.1972-10.1978 |
| VOLVO | FB 85T 5.0 | [TD50B] | 01.1972-10.1978 |
| VOLVO | FB 86 6.7 | [D70B] | 06.1970-12.1974 |
| VOLVO | FB 86T 6.7 | [TD70B] | 08.1970-09.1974 |
| VOLVO | L 375 Strake 4.7 | [D47A] | 01.1959-12.1961 |
| VOLVO | L 465 4.7 | [D47B] | 06.1961-05.1965 |
| VOLVO | L 4751 4.7 | [D47B] | 10.1964-12.1965 |
| VOLVO | L 4751 4.7 | [TD47B] | 10.1964-12.1965 |
| VOLVO | L 475 4.7 | [D47B] | 06.1961-05.1965 |
| VOLVO | L 475 4.7 | [TD47B] | 06.1961-05.1965 |
| VOLVO | N 7 6.7 | [TD70B] | 09.1973-07.1978 |
| VOLVO | N 84 5.0 | [D50B] | 01.1972-08.1973 |
| VOLVO | N 86T 6.7 | [TD70B] | 08.1970-08.1973 |
| VOLVO | NB 84 5.0 | [D50B] | 01.1972-08.1973 |
| VOLVO | NB 86 6.7 | [D70B] | 06.1970-08.1973 |
| VOLVO | NB 86T 6.7 | [TD70B] | 08.1970-08.1973 |
| VOLVO BM | S950 5.0 | [D50A] | 02.1966-12.1970 |
| VOLVO BM | T800 5.0 | [D50A] | 01.1967-12.1975 |
| VOLVO BM | T810 5.0 | [TD50A] | 03.1969-12.1975 |
| VOLVO BM | T814 5.0 | [TD50A] | 03.1969-06.1979 |
Reference Information
861067 11.139.530 STR10320 05710993 51262017008 233991 51.26201-7008 5010314 240847 CST10175ES 88262016002 240524 CST10175AS 0001413010 33653 UD16933S 01304445 331181 790.101.093.380 1304445 88213065 790.101.093.016 A0031514401 110538 20401571BN 88.26201-6002 120-6193B 0031514401 790.101.093.010 51262019008 111217 240500 240501 STR50556 MAV121750A 0001418003 MS716 51.26201-9008 847306 842775 8882 790.101.093.311 A0041514001 0001401052 881681 0001401012 20401571EL 05710906 837924 STB0151 3109 6643669 6643900 0041514001 6010175.3 6010175.0 843511 CS956 7240524Video/Publications
