Specifications
Kilowatt | 6.6 kW |
Length (L.1) | 405 mm |
Mount Hole Center - Center (O.1) | 99 mm |
Mount Hole Center - Center (O.2) | 99 mm |
Mount Hole Center - Center (O.3) | 140 mm |
Mount Hole Diameter (C.1) | 12.5 mm |
Mount Hole Diameter (C.2) | 12.5 mm |
Mount Hole Diameter (C.3) | 12.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 20 mm |
Rotation | CW |
Spigot Diameter (A) | 102 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
RENAULT V.I. | Various Models |
Reference Information
5001825905 8125 5001822955 CST10653ES 442100118 220266 MAV126530 6010653.3 20401356BN CST10653AS STRJ374 UD16947S 6010653 5001825908 19024184 5010217010 5001014200 20401356ELVideo/Publications
19024184 20401356BN 20401356EL 5010217010 6010653.0 6010653.3 8125 CST10653AS CST10653ES MAV126530 STRJ374 UD16947S 220266Add Your Number
