Specifications
| Kilowatt | 3.1 kW |
| Length (L.1) | 325 mm |
| Mount Hole Center - Center (O.1) | 103 mm |
| Mount Hole Diameter (C.1) | 14 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 35 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| JOHN DEERE | 6500 | 01.1993-12.2007 | |
| JOHN DEERE | 6600 | 01.1996-12.2006 |
Reference Information
BOM 120-500D UNIT 0001369021 91-15-7064 1369021 260-69123 120-30151 UD16930SVideo/Publications
0001369021 120-30151 260-69123 91-15-7064 UD16930S UNIT BOM 120-500DAdd Your Number
