Specifications
| Kilowatt | 3 kW |
| Length (L.1) | 341 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 125 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 48 mm |
| Rotation | ACW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | Various Models | 01.1985- |
Reference Information
STR1457 1367061 0001367061 255485 8472 20401104BN STRS455 630.012.093 UD16929S LRS1600 LRS01600 17308R BOS0001367061 17308N TS-6075 25-3119 STB7061 245927C93 91-15-7022 245927C91 260-67112 88214824 CST10401AS EAA-111774 6010401Video/Publications
0001367061 17308N 17308R 20401104BN 245927C93 25-3119 255485 260-67112 6010401.0 630.012.093 8472 88214824 91-15-7022 BOS0001367061 CST10401AS EAA-111774 LRS01600 LRS1600 STB7061 STRS455 TS-6075 UD16929SAdd Your Number
