Specifications
Kilowatt | 2 kW |
Length (L.1) | 256.5 mm |
Mount Hole Center - Center (O.1) | 101 mm |
Mount Hole Diameter (C.1) | 16 mm |
Mount Hole Diameter (C.2) | M12x1.75 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 27 mm |
Rotation | CW |
Spigot Diameter (A) | 76 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VW | Passat 4.0 W8 | [BDN] | 01.2002-12.2003 |
VW | Passat 4.0 W9 | [BDP] | 01.2002-12.2003 |
VW | Phaeton 4.2 V8 | [BGH] | 01.2003- |
VW | Phaeton 4.2 V9 | [BGJ] | 01.2003- |
Reference Information
CST10178RS BOM UNIT 120-342A 1109059 ANM16153X STR1947 91-15-7228 254289R 20401871RC MAV121780 UD20347S 6010178.2 DRS3933 STRF280 25-3215 LRS1669 0001109059 STB4959 3965 LRS01669 07D911023A 07D911023Video/Publications
0001109059 20401871RC 25-3215 254289R 3965 6010178.2 91-15-7228 CST10178RS DRS3933 LRS01669 LRS1669 MAV121780 STB4959 STRF280 UD20347S UNIT BOM 120-342AAdd Your Number
