Specifications
Kilowatt | 3.6 kW |
Length (L.1) | 387 mm |
Mount Hole Center - Center (O.1) | 126.5 mm |
Mount Hole Center - Center (O.2) | 126.5 mm |
Mount Hole Center - Center (O.3) | 126.5 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
Mount Hole Diameter (C.3) | 13.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Oil Sealed | Yes |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MAGIRUS-DEUTZ | Various Models |
Reference Information
510.007.113 BOM UNIT TS-6123 19024006 STB4810 120-580 UD16658S STR50559 0001418010 260-46106 61585080 1418010Video/Publications
0001418010 19024006 260-46106 510.007.113 61585080 STB4810 STR50559 TS-6123 UD16658S UNIT BOM 120-580Add Your Number
