Specifications
| Kilowatt | 6.6 kW |
| Length (L.1) | 406 mm |
| Mount Hole Center - Center (O.1) | 117 mm |
| Mount Hole Center - Center (O.2) | 117 mm |
| Mount Hole Center - Center (O.3) | 140 mm |
| Mount Hole Diameter (C.1) | 15.5 mm |
| Mount Hole Diameter (C.2) | 15.5 mm |
| Mount Hole Diameter (C.3) | 15.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| Oil Sealed | Yes |
| Pinion at Rest (B) | 21 mm |
| Rotation | CW |
| Spigot Diameter (A) | 115 mm |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| VOLVO | Various Models |
Reference Information
STB2125 0001417096 1417096 UD16651SVideo/Publications
0001417096 STB2125 UD16651SAdd Your Number
