Specifications
| Insulated Earth | Yes |
| Kilowatt | 6.6 kW |
| Length (L.1) | 406 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 127 mm |
| Mount Hole Diameter (C.1) | 13 mm |
| Mount Hole Diameter (C.2) | 13 mm |
| Mount Hole Diameter (C.3) | 13 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Oil Sealed | Yes |
| Pinion at Rest (B) | 47 mm |
| Rotation | CW |
| Spigot Diameter (A) | 92 mm |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MERCEDES BENZ TRUCKS & BUSES | 1932 AK 16.0 | [OM403.916] | 08.1973-09.1983 |
| MERCEDES BENZ TRUCKS & BUSES | 1932 AK 16.0 | [OM403.931] | 08.1973-09.1983 |
Reference Information
51262017129 9.43252E+11 STB2120 11.139.091 18375N 31516401 1516711R A0021512801 MS579 S0817S UD16638S 15196711R 1411022 254328 31516201 51262017124 72736207 51262017114 6010779 8700 21512801 MS MSR718 0001330066 0001411022 51.26201-7091 STR79524 51262017271 112120 11129122 LRS1877 33647 IS9082 MAV126020 551.205.093 CST10779AS 19070004 AZK5443 88213408 254328P 579 0001417037 STR50670 51262017137 20401977BN 51262017139 331907 STR1321 260-47245 120-40122 1330066 A0031516201 A0031516401 860698GB 1417037 45-1403 91-15-7160 LRS01877 PRE860698GBVideo/Publications
0001330066 0001411022 0001417037 0031516201 0031516401 11.139.091 11129122 112120 120-40122 1516711R 18375N 19070004 20401977BN 254328 254328P 260-47245 33647 45-1403 51262017114 51262017124 51262017129 51262017137 51262017139 551.205.093 6010779.0 72736207 860698GB 8700 88213408 91-15-7160 943252236010 A0031516201 A0031516401 AZK5443 CST10779AS IS9082 LRS01877 LRS1877 MAV126020 MS 579 MS579 MSR718 PRE860698GB STB2120 STR50670 UD16638SAdd Your Number
