Specifications
| Kilowatt | 5.4 kW |
| Length (L.1) | 386 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Oil Sealed | Yes |
| Pinion at Rest (B) | 47 mm |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| VOLVO | L60E 5.7 | [D6D] | 01.2002-12.2007 |
| VOLVO | L70E 5.7 | [D6D] | 01.2002-12.2007 |
| VOLVO | L90E 5.7 | [D6D] | 01.2002-12.2007 |
Reference Information
88214022 CST10731AS 8297 19082027 LRS2733 CST10731ES STB6080 TS-6207 UD16628S 45-4406 254322M 254322 20401137EL DRS0155 0001416080 DS1265 6010731 19024192 LRS02733 6010731.3 BOM 811.210.093 UNIT 260-46296 120-40121 1181681 STR50644 91-15-7164 20459062 20401137BN 120-6431 1416080 ANM12375X STRL318 BOS0001416080Video/Publications
0001416080 01181681 120-40121 19024192 19082027 20401137BN 20401137EL 20459062 254322 254322M 260-46296 45-4406 6010731.0 6010731.3 811.210.093 8297 88214022 91-15-7164 BOS0001416080 CST10731AS CST10731ES DRS0155 DS1265 LRS02733 LRS2733 STB6080 STR50644 STRL318 TS-6207 UD16628S UNIT BOM 120-6431Add Your Number
