Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 806.18 including GST
NZ$ 701.03 excluding GST
or four payments of $201.55
with
Learn More
each
S0801S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Information
0001416074Specifications
| Insulated Earth | Yes |
| Kilowatt | 5.40 kW |
| Length (L.1) | 387 mm |
| Mount Hole Center - Center (O.1) | 126 mm |
| Mount Hole Center - Center (O.2) | 126 mm |
| Mount Hole Center - Center (O.3) | 126 mm |
| Mount Hole Diameter (C.1) | 13.50 mm |
| Mount Hole Diameter (C.2) | 13.50 mm |
| Mount Hole Diameter (C.3) | 13.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Oil Sealed | Yes |
| Pinion at Rest (B) | 47.50 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 92 mm |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MAN | 11.220 6.9 | [D0826LUH12 | 01.1998-12.2000 |
| MAN | 13.220 6.9 | [D0826LUH12] | 01.1998-12.2001 |
| MAN | 14.220 6.9 | [D0826LUH12] | 01.1998-12.2001 |
| MAN | EL 202 6.9 | [D0826LUH] | 01.1993-12.1997 |
| MAN | EL 202 F 6.9 | [D0826LUH] | 01.1996-12.1997 |
| MAN | EL 220 6.9 | [D0836LUH12] | 01.1995-12.2001 |
| MAN | EL 222 6.9 | [D0826LUH12] | 01.1995-12.2001 |
| MAN | EL 262 6.9 | [D0826LUH13] | 01.1996-12.2001 |
| MAN | EM 13.222 6.9 | [D0826LUH12] | 01.1997-12.2001 |
| MAN | ND 222 6.9 | [D0826LUH12] | 01.1997-12.2001 |
| MAN | NG 262 6.9 | [D0826LUH13] | 01.1997-12.1998 |
| MAN | NG 272 6.9 | [D0826LUH] | 01.1990-12.1995 |
| MAN | NL 202 6.9 | [D0826LUH] | 01.1994-12.1997 |
| MAN | NL 222 6.9 | [D0826LUH12] | 01.1995-12.2001 |
| MAN | NL 223 F 6.9 | [D0826LUH12] | 01.1996-12.2001 |
| MAN | NL 262 6.9 | [D0826LUH13] | 01.1996-12.2001 |
| MAN | NM 222 F 6.9 | [D0826LUH12] | 01.1997-12.2001 |
Reference Information
| 0001416074 | BOSCH |
| 0041516801 | MERCEDES |
| 101178 | KUHNER |
| 11.139.127 | ISKRA / LETRIKA |
| 1516681R | DAF |
| 19024109 | DELCO |
| 20401827BN | REAL |
| 20401827EL | REAL |
| 220290 | ERA |
| 260-46246 | DIXIE |
| 45-2469 | ELSTOCK |
| 458337 | VALEO |
| 51262017108 | MAN |
| 51262017127 | MAN |
| 51262017151 | MAN |
| 51262019117 | MAN |
| 551.201.093 | PSH |
| 6010728.0 | SANDO |
| 6010728.3 | SANDO |
| 72736093 | MAHLE |
| 8437 | CEVAM |
| AZK5476 | ISKRA / LETRIKA |
| CST10728AS | CASCO |
| CST10728ES | CASCO |
| IS9114 | ISKRA / LETRIKA |
| LRS01932 | LUCAS |
| LRS1932 | LUCAS |
| MS465 | MAHLE |
| S133.113 | PSH |
| S144.984 | PSH |
| STB1178 | KRAUF |
| STR79553 | ELECTROLOG |
| STRS966 | 3EFFE |
| UD16627S | AS-PL |
| UNITBOM120-6386 | WAI / TRANSPO |
Video/Publications
