Specifications
B+ Stud Diameter & Thread Pitch (B+d) | M8x1.25 mm |
B+ Thread Length (B+H) | 20.8 mm |
D+ Stud Diameter & Thread Pitch (D+d) | M8x1.25 mm |
D+ Thread Height (D+H) | 8.5 mm |
Diode Amp Rating | 60 A |
Diodes (Main) | 6 qty |
Inside Diameter (I.D.1) | 29 mm |
Outside Diameter (O.D.1) | 129 mm |
Reg/Rec Combo | No |
Source | ∆ |
Unit Type | BOSCH |
With Attached Bracket | No |
Reference Information
UD18767ARCVideo/Publications
124655632 0124655305 0124655632 UD18767ARC A0759SAdd Your Number
