Brand new AS-PL Alternator
STANDARD LINE
AS-PL
ISKRA / LETRIKA
Price:
NZ$ 367.87 including GST
NZ$ 319.89 excluding GST
or four payments of $91.97
with
Learn More
each
A9323S
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 55 A |
| Bottom Mounting Foot Width (B) | 10.5 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 8 mm |
| Diameter (D.3) | 8 mm |
| Length (L.1) | 178 mm |
| Mount Inside Length or Pad Mount C-C (C) | 85 mm |
| OEM Product | No |
| Plug Code | PL_3200 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 5 qty |
| Pulley Outside Diameter (O.D.1) | 60 mm |
| Pulley to Mount Distance (A) | 25.5 mm |
| Pulley Type | SOLID |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | 1394 2WD | 01.1984-01.1988 | |
| CASE | 1494 2WD | 01.1984-01.1987 | |
| CASE | 1594 2WD | 01.1984-01.1988 | |
| CASE | 1690 2WD | 01.1984-01.1985 | |
| CASE | 1690 4WD | 01.1984-01.1985 | |
| CASE | 1694 | 01.1984-01.1987 | |
| NEW HOLLAND | 8055 | 01.1985- | |
| NEW HOLLAND | 8060 | 01.1985- | |
| VALTRA | 1394 | 01.1984- | |
| VALTRA | 1494 | 01.1984- | |
| VALTRA | 1594 | 01.1984- | |
| VALTRA | 1694 | 01.1984- | |
| VALTRA | 365 | [320DS] | |
| VALTRA | 465 | [320DS] | |
| VALTRA | 505 | [TD33DS5] | |
| VALTRA | 565 | [320DS] | |
| VALTRA | 6000 | 01.1990- | |
| VALTRA | 605 | [TD33DS6] | |
| VALTRA | 6100 | ||
| VALTRA | 6300 4.4 | [420SRE] | |
| VALTRA | 6300 4.4 | [44DT] | |
| VALTRA | 6400 | [420DS] | |
| VALTRA | 6600 | [320DS] | |
| VALTRA | 6600 | [420DS] | |
| VALTRA | 665 | [420D] | |
| VALTRA | 705 | [TD44DS7] | |
| VALTRA | 8000 | [620DS] | |
| VALTRA | 805 | [TD44DS8] | |
| VALTRA | 8050 | [620DS] | |
| VALTRA | 8100 | [620D] | 01.1990- |
| VALTRA | 8150 | [620DS] | |
| VALTRA | 8200 | [620D] | 01.1990- |
| VALTRA | 8350 | [620DSI] | |
| VALTRA | 8400 | [620D] | 01.1990- |
| VALTRA | 8400 | [620DS] | |
| VALTRA | 8450 | [620DS] | |
| VALTRA | 8450 6.6 | [620DW] | 01.1996- |
| VALTRA | 865 | [420DS] | |
| VALTRA | 905 | [D66D9] | |
| VALTRA | C100 | [420D] | 01.1997- |
| VALTRA | C100 | [420DS] | |
| VALTRA | C15 | [420D] | |
| VALTRA | C20 | [420D] | |
| VALTRA | C200 | [420D] | 01.1997- |
Reference Information
GEU2115 ADU9750 STX100529 72735101 50249415 ADU9670 MAHMG102 2021240.1 20119042OE DRA3464 3698017M91 R86AX10300DB ALT3650 3698015R91 1897695R91 873F10300BA 1005349 3930501R91 110770 89213119 432987 K311697 STX110141 K311698 CAL21240GS DA4574 2871A141 90-23-6515 2871A147 A-9317 11.201.707 YLE10066 3698016M91 2871A148 STX101112 ASU1693 1406058 ADU9052 86VB10300AA MG102 STX101521 2871A154 ADU8880 24208A 1695614M91 282-30223 AAK5468 YLE10011 IA0707 436263 210204 VA110 ALI2678 91FF10300VA 1447701R91 ADU8090 UD17191A CGB-13760 714/12500 3476244M91 STX101805 ALT79159 86VB10300A2 ADU9548 86VB10300A2A RTC5845 CA600IR STX100480 GXE2115Video/Publications
A9323SRelated Items
