Specifications
Amp | 35 A |
Bottom Mounting Foot Width (B) | 13 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 12 mm |
Diameter (D.3) | 12 mm |
Grooves | 2 qty |
Groove Width (W.1) | 10 mm |
Length (L.1) | 175 mm |
Mount Inside Length or Pad Mount C-C (C) | 56 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 63.5 mm |
Outside Diameter (O.D.2) | 84 mm |
Plug Code | PL_2003 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 40 mm |
Pulley Type | SOLID |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CATERPILLAR | 305 2.29 | [K4N140CI] | 01.1999-12.2010 |
CATERPILLAR | 305.5 2.85 | [4M40] | 01.2002-12.2009 |
CATERPILLAR | 306 2.85 | [4M40] | 01.2002-12.2009 |
CATERPILLAR | 307B 2.85 | [4M40] | 01.1996-12.2001 |
CATERPILLAR | 307C 2.85 | [4M40] | 01.2000-12.2009 |
CATERPILLAR | 307C SB 2.85 | [4M40] | 01.2000-12.2009 |
CATERPILLAR | 307D 2.85 | [4M40] | 01.2008-12.2013 |
CATERPILLAR | 308C 2.85 | [4M40] | 01.2002-12.2009 |
CATERPILLAR | 308C CR 2.85 | [4M40] | 01.2002-12.2019 |
CATERPILLAR | 308D 2.85 | [4M40] | 01.2008-12.2013 |
CATERPILLAR | 313B | [4D34T] | 01.1996-12.2002 |
Reference Information
A-80064 2035642.1 CAL35642GS 5635138 20137246OE CAL35642AS 553771RI 1397850 A24MH0129A2 156.507.035 A003TA8199 230-30127 2035642 143-36201 20059N UD18512A A3TA8199 ME108147 ALTL579 20137246BN ALM0169 A003T8199Video/Publications
1397850 143-36201 156.507.035 20059N 20137246BN 20137246OE 2035642.0 2035642.1 230-30127 553771RI A-80064 A003TA8199 A3TA8199 ALM0169 ALTL579 CAL35642AS CAL35642GS ME108147 UD18512AAdd Your Number
