Specifications
| Amp | 150 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Grooves | 6 qty |
| Length (L.1) | 197 mm |
| Mount Inside Length or Pad Mount C-C (C) | 60.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 55 mm |
| Plug Code | PL_3308 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 39 mm |
| Pulley Type | CLUTCH |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| NISSAN | Juke 1.5 dCi | [K9K..] | 01.2013- |
| NISSAN | Note 1.5 dCi | [K9K..] | 01.2013- |
| NISSAN | NV200 1.5 | [K9K..] | 01.2009- |
| NISSAN | NV200 1.5 | [K9K..] | 01.2011- |
| NISSAN | NV200 1.5 dCi | [K9K..] | 01.2013- |
Reference Information
554496RI DA2683 28-7549 2035402 UD18469A 21192N A3TJ4081ZE A5397S CGB-87549 20137204BN 23100-3VD1A LRA03939 57706 21192-OS 40014 A003TJ4081ZE ALT31386 447005 CAL35402AS AEG1272 A003TJ4081 A3TJ4081 ALT5503 DRA1573 LRA3939 23100-3VDIA 165.913.150.130 89216053 ALM4108Video/Publications
165.913.150 20137204BN 2035402.0 21192-OS 23100-3VD1A 23100-3VDIA 28-7549 40014 554496RI 57706 A003TJ4081 A003TJ4081ZE A3TJ4081 A3TJ4081ZE ALM4108 ALT31386 CAL35402AS CGB-87549 DA2683 DRA1573 LRA03939 LRA3939 UD18469AAdd Your Number
