Specifications
Amp | 180 A |
Diameter (D.1) | 9 mm |
Diameter (D.2) | 9 mm |
Diameter (D.3) | 8.5 mm |
Diameter (D.4) | 8.5 mm |
Grooves | 6 qty |
Length (L.1) | 193 mm |
Mount Inside Length or Pad Mount C-C (C) | 56 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 64.5 mm |
Pad mount thickness (E.1) | 70 mm |
Pad mount thickness (E.2) | 70 mm |
Plug Code | PL_2306 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Type | CLUTCH |
Pulley to Mount Distance (A) | 30 mm |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
AUDI | A6 2.8 FSi | [CHVA] | 01.2010- |
AUDI | A6 2.8 FSi Quattro | [CHVA] | 01.2010- |
AUDI | A6 3.0 TFSi Quattro | [CGWB] | 01.2010- |
AUDI | A6 3.0 TFSi Quattro | [CGWD] | 01.2010- |
AUDI | A6 3.0 TFSi Quattro | [CGXB] | 01.2010- |
AUDI | A6 3.0 TFSi Quattro | [CTUA] | 01.2010- |
AUDI | A7 2.8 FSi | [CHVA] | 01.2010- |
AUDI | A7 2.8 FSi Quattro | [CHVA] | 01.2010- |
AUDI | A7 2.8 FSi Quattro | [CNYA] | 01.2010- |
AUDI | A7 3.0 TFSi Quattro | [CGWD] | 01.2010- |
AUDI | A7 3.0 TFSi Quattro | [CGXB] | 01.2010- |
AUDI | A7 3.0 TFSi Quattro | [CTTA] | 01.2010- |
AUDI | A7 3.0 TFSi Quattro | [CTUA] | 01.2010- |
Alternatives >>>
AGV-C6153 - OEM VALEO Alternator - Will replace HITACHI Version
AAM-C6153 - +Plus Line Pro Alternator ( Valeo style, OEM Regulator and INA Pulley) Will replace HITACHI
A3471S - ASPL Standard line - Valeo Style Aftermarket Regulator and Pulley
A2073PR - Remanufactured HITACHI Alternator
AGH-C6153 - OEM HITACHI Alternator - Coming Soon
Reference Information
06E903018N 06E903018M LRA03921 06E903018NX ALH8501 06E903018S ALT00663 6E903018M 205.557.180 2020235.1 6E903018MX 6E903018N 554439RIH 6E903018S 06E903018G L06E903018N 06E903018SX ALTE931 2506164 440605 06E903018MX LRA4596 ALT32238 6E903018G LRA04596 6E903018NX LR1180858 UD17227A 439867 FGN20S019 LR1180851 CAL20235GS LR1180858S 4310 A12VA0755AS 20145532OE 6E903018SX 06E903019FX 57645 LRA3921 FG20S012 6E903018GX LR1110858S UD17232A A12VA0755 06E903018GX FG20S019 55151159 28-8705 06E903019A 06E903019AX DRA1278 28-7531 06E903019F ALTE348Video/Publications
06E903018G 06E903018M 06E903018MX 06E903018S 06E903018SX 20145532OE 2020235.1 205.557.180 28-7531 4310 439867 440605 554439RIH 57645 ALH8501 ALT32238 ALTE348 ALTE931 CAL20235GS DRA1278 FG20S012 FG20S019 FGN20S019 LR1180851 LR1180858 LR1180858S LRA03921 LRA3921 UD17227A UD17232AAdd Your Number
