Specifications
| Amp | 180 A |
| Diameter (D.1) | 9 mm |
| Diameter (D.2) | 9 mm |
| Diameter (D.3) | 8 mm |
| Diameter (D.4) | 8 mm |
| Grooves | 6 qty |
| Length (L.1) | 188 mm |
| Mount Inside Length or Pad Mount C-C (C) | 56 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 50 mm |
| Pad mount thickness (E.1) | 70 mm |
| Pad mount thickness (E.2) | 70 mm |
| Plug Code | PL_2306 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 31.5 mm |
| Pulley Type | SOLID |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MERCEDES BENZ | C 250 2.2 CDi 4-Matic | [OM651.912] | 01.2010- |
| MERCEDES BENZ | E 250 2.2 CDi 4-Matic | [OM651.924] | 01.2009- |
| MERCEDES BENZ | GLK 220 2.2 CDi 4-Matic | [OM651.912] | 01.2008- |
| MERCEDES BENZ | GLK 250 2.2 CDi 4-Matic | [OM651.912] | 01.2009- |
Reference Information
209182 4232 ALV8083 LRA3373 A0009060601 440335 115580 ALT2269 ALT00024 28-5985 DRA1068 2015428.1 A3459S UD17222A FGN18S083 FG18S083 555.908.180 55151239 LRA03373 ANM33288X 20179824OE 2612242A VAL439745 A12VA0962AS 439745 CAL15428GS 9060601 553641RIVVideo/Publications
0009060601 115580 2015428.1 20179824OE 209182 2612242A 28-5985 4232 439745 440335 553641RIV 555.908.180 A0009060601 ALT2269 ALV8083 CAL15428GS DRA1068 FG18S083 FGN18S083 LRA03373 LRA3373 UD17222A VAL439745 A3459SAdd Your Number
